WSL36372L000FEA Original Electronic Component/ IC Chips
Product Attributes
| TYPE | DESCRIPTION |
| Category | Resistors |
| Chip Resistor - Surface Mount |
| Mfr | Vishay Dale |
| Series | WSL |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) |
| Digi-Reel® |
| Product Status | Active |
| Resistance | 2 mOhms |
| Tolerance | ±1% |
| Power (Watts) | 3W |
| Composition | Metal Element |
| Features | Anti-Sulfur, Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding |
| Temperature Coefficient | ±75ppm/°C |
| Operating Temperature | -65°C ~ 170°C |
| Package / Case | Nonstandard |
| Supplier Device Package | 3637 |
| Ratings | AEC-Q200 |
| Size / Dimension | 0.360" L x 0.370" W (9.14mm x 9.40mm) |
| Height - Seated (Max) | 0.035" (0.89mm) |
| Number of Terminations | 4 |
Documents & Media
| RESOURCE TYPE | LINK |
| Datasheets | WSL3637 |
| PCN Design/Specification | WSL WSK 28-Feb-2022 |
| HTML Datasheet | WSL3637 |
| EDA Models | WSL36372L000FEA - Models |
| Part Numbering Guide | Wirewound Resistors Part Numbering Manual |
| Forum Discussions | Cracking issue on Vishay WSL series Resistors |
Environmental & Export Classifications
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| ECCN | EAR99 |
| HTSUS | 8533.21.0030 |
Additional Resources
| ATTRIBUTE | DESCRIPTION |
| Other Names | 541-10092-6 |
| 541-10092-1 |
| 541-10092-2 |
| Standard Package | 4,000 |
FAQ
Q1: What is your MOQ?
A:Minimum order quantity starts from ONE piece,it depends your specific order!
Q2: How about your delivery time?
A:Generally, goods would be shipped in 3-5 work days after payment received, finally depends on order quantities.
Q3: HOW can we get samples from you?
A:Samples are available. Normally we take 2 days to arrange samples. If we have no business record with you before, we need to
charge boot samples cost and post courier freight.
Q4):What is your products quality?Do you test all your goods before delivery?
A:Yes,We have 100% test before delivery,We can make sure all the items from our company is 100% new & original .
Q5:Can l get a discount if l make a larger order?
A:Yes, the more pieces you purchase, the higher the discount. If your purchasing order amount reaches or exceeds $1,000, we would be happy to provide you with a big order quoted price.
Any other more questions, please feel free to contact us. We are always at your service !
